Semi Automatic Aluminium Plate Pneumatic Eyelet Punching Machine

The equipment can punching the PCB circuit boards, FPC flexible boards, IMD/IML, filaments, diazo sheets, mobile phone panels, mobile phone keys, stickers, membrane switches, films, PE, PC, PVC, PET film, polyester film, thin aluminium, aluminium substrates, FR4 glass fibre boards and many other materials.

CCD visual positioning and automatic punching analysis:

1. This machine have XYθ alignment platform and CCD system to make the alignment smooth.

2. The loading suction platform fixing the material, easy to operate.

3. Punching and cutting accuracy is completely controlled by CCD, accurate positioning.

4. Human-machine interface control + button switch, can set a variety of functions and parameters, easy to operate.

5. Safety pressure plate, photoelectric switch, emergency stop button, thorough safety protection.

6. CCD automatic positioning punching and cutting, can automatically adjust the field of view of CCD according to the size of the material.

7. CCD automatically calculates the spatial position of the material and the mold according to the Mark point on the material, and instructs the motor motion control to adjust the platform X, Y, θ, and automatic punching .

8. Can be customized according to customer requirements to meet different use requirements.
